Practise electrical troubleshooting with realistic faults, virtual tools, and guided diagnostics across Electrical Diagnostics and Commercial & Industrial systems.
Safety included with every paid plan.
Practical electrical training requires repetition, but lab time, equipment availability, and instructor capacity are limited. TradeRig gives learners a safe place to practise before working on physical systems.
Apprentices need to run faults again and again. A shared bay can't give everyone the time.
Training rigs are expensive and often in use. Equipment access becomes the bottleneck.
A wrong probe or a reversed connection on a live harness can damage components and add cost.
Instructors have little insight into who understands diagnosis until it shows up on the job.
The same diagnostic loop a technician follows, practised safely in the browser.
Drag components onto the canvas and wire up a 12V/24V circuit.
Inject a fault (open, short, bad ground, blown fuse) or let a scenario surprise you.
Probe with a virtual multimeter and test light.
Follow the evidence to the root cause.
Make the repair, run it again, confirm it works.
Electrical Diagnostics and Commercial & Industrial Electrical, with safety fundamentals included in every paid plan.
Build circuits, inject faults, and trace them with real test tools: relays, grounds, loads, fuses, and voltage drop across live systems.
LiveStep up to 3-phase distribution, transformers, motor control, and the control-circuit logic behind industrial equipment.
LiveLockout / tagout, PPE, and hazard recognition. The safety fundamentals behind sound electrical work. Included with every paid plan.
IncludedA full toolkit around the canvas, giving learners the tools and feedback they need to diagnose with confidence.
Batteries, fuses, relays, loads, and more.
Open circuits, shorts, bad grounds, blown fuses.
Probe voltage, continuity, and current. Blow the fuse if you measure amps wrong.
Live hints and guidance as you work.
Clear steps to follow, plus open challenges.
Scores, attempts, and skill insights.
Every run saved and reviewable.
Practise realistic circuit behaviour and build confidence before working on live systems.
Assign diagnostic exercises, track who understands each fault, and focus class time where it counts.
Build the crew's diagnostic confidence with consistent, repeatable practice.
Run your class on the same platform your students use. Create classes by trade, assign the right labs, and track progress by fault type and attempt. Students join with a code.
Book a DemoChoose one electrical lab or access both. Safety is included with every paid plan.
Monthly and yearly plans available. No install required.
Two technical labs are available: Electrical Diagnostics and Commercial & Industrial Electrical. Safety is included with every paid plan.
Electrical Diagnostics covers circuits, relays, grounds, loads, and fault tracing. Commercial & Industrial Electrical steps up to 3-phase distribution, transformers, and motor control.
No. TradeRig runs in your browser.
Apprentices, instructors, trade schools, shops, and training teams.
Open TradeRig in your browser and begin with the live Electrical Diagnostics demo. No install required.
